Torroja Tiered Mobile No. 429

By David Weeks

Starting at: $26,985.00

Torroja Tiered Mobile No. 429

By David Weeks

Starting at: $26,985.00

Inspired by the architecture of Spanish engineer Eduardo Torroja, the Torroja Mobile is hand-made to measure. With a minimum of two tiers, the mobile can be extended horizontally and vertically. Each tier is comprised of three segments, each balanced on an asymmetrical axis allowing for gentle movement. Torroja shades rotate 320 degrees to cast light up or down.

10-12 Weeks Lead-Time

Shade

Finish

Technical Specifications

Designer

David Weeks

Lead Time

10-12 Weeks

Origin

United States

Production

Made to Order

Materials

Powder-Coated Aluminum Shade, Plated Steel Frame, Powder-Coated Steel Canopy, Stainless Steel Drop.

Dimensions

Canopy: Dia. 5"

2-Tier Fixture: Dia. 60" x H 24"

3-Tier Fixture: Dia. 60" x H 31"

Shade: Dia. 4" x L 18.5"

Overall Height: Custom length made to order.

Weight

Approx. 10 lbs. per tier.

Customizable

Additional tiers are available at an additional cost. Please inquire directly for more information.

Illumination

120V: (3) T10 tubular incandescent medium base, Max 60W.

220-240V: (3) E27 base (tubular 32mm suggested), Max 60W.

Max 180 Watts.

Suspension

Pendant lengths are pre-set during production and are not site adjustable. Lengths are determined by client upon order confirmation.

Certifications

UL, CE.

Disclaimer

Additional weight support is recommended for junction box installation. Indoor use and dry locations only. Bulbs not included. Halogen bulbs not recommended.
