The OTTO X features two intersecting arms made of tubular brass, each featuring a pair of aluminum powder coated shades. Both arms extend from a customizable drop with a naturally occurring arc; all four shades contain dimmable LED. The drop has a 245 degree range of rotation from the canopy; each shade also rotates 300 degrees.
OTTO X No. 448
By & David Weeks
Price Upon Request
Inquire
ADD TO PROJECT
QUESTIONS?
ADD TO PROJECT
ADD TO PROJECT
ADD TO PROJECT
Technical Specifications
Designer
Origin
Made in the United States.
Production
Made to Order
Materials/Finishes
Powder coated aluminum shades, powder coated and plated aluminum ceiling mount, plated brass frame and drop, plated and polished brass hardware.
Black Satin (ivory satin interior), Grey Gloss (ivory satin interior), Ivory Satin (ivory satin interior) shade. Custom shade colors available upon request. Brushed brass or polished nickel finish. Hardware finish consistent with frame finish. Ceiling mount consistent with shade color.
Dimensions
D 4.5" x W 98” x H 74.5”
Shade: Dia 1.5” x L 28”
Min overall height: 74”
Weight
10lbs
Care
Additional weight support recommended for junction box installation. Indoor use and dry locations only.
Illumination
LED Warm white 2700K, 3360 Lumens (equivalent to four 60W incandescent bulbs), 50,000 LED life hours.
120V: 60W, 24V phase dimmable class 2 included in canopy.
220-240V: remote power supply only. Not included.
MLV/TRIAC (leading edge) switch dimmer compatibility.
24V / 44 watts
Suspension
Black exterior electrical cord is standard. Specify drop length. Fixed drop not adjustable on site. Arm length is fixed. Not for use on sloped ceilings.
Canopy
Dia 9” x H 3.5”
Product Downloads
Tearsheet
